Noah Tubefittings is a well-respected manufacturer and supplier located in Kinshasa, Congo, specializing in high-quality **Hydraulic Equal Tee** fittings that are built for dependable performance in high-pressure hydraulic systems. These fittings are expertly designed to connect three hydraulic lines of the same size, facilitating efficient fluid flow distribution and control. With a commitment to using cutting-edge technology and top-notch materials, Noah Tubefittings guarantees outstanding strength, resistance to corrosion, and precise dimensions. Their Hydraulic Equal Tee fittings are highly regarded for providing leak-proof connections, durability, and long-lasting reliability in challenging industrial settings.

Hydraulic Equal Tee Supplier in Kinshasa, CS Hydraulic Equal Tee Manufacturer in Lubumbashi, Congo, DIN 2353 Hydraulic Tee Exporter in Mbuji-Mayi, Hydraulic Equal Tee Assembled & Un Assembled Supplier in Kinshasa, CS Hydraulic Equal Tee Exporter in Kananga, DIN 2353 Hydraulic Tee Manufacturer in Lubumbashi, Congo, Hydraulic Equal Tee Manufacturer in Mbuji-Mayi

Typically crafted from stainless steel, carbon steel, or alloy steel, Hydraulic Equal Tee fittings offer remarkable mechanical strength and corrosion resistance. They boast tensile strength between 520 MPa and 800 MPa, along with exceptional resistance to pressure changes, vibrations, and mechanical stress. These tees are designed with smooth internal surfaces to ensure optimal flow and minimal pressure loss, maintaining stability and performance even under extreme temperature or pressure conditions.

Hydraulic Equal Tee Specifications

STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20
MATERIAL
SERIES	LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
CONNECTIONS	TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE
CONNECTIONS	WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL
BODY TYPE	FORGED, BAR STOCK
SURFACE	CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED,
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	STEEL – (-40* C TO 120C) ,STAINLESS STEEL – (-60C TO 400C) BRASS – (-60C TO 175*C)
EQUIVALENT BRANDS	PARKER, HY-LOK , DK-LOK , STAUFF, HYDAC , VOSS
APPLICATIONS & INDUSTRIES	CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT

Top Hydraulic Equal Tee Manufacturing Company in Kinshasa

At Noah Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Equal Tee in Kinshasa, Congo. Our advanced manufacturing facilities, strategically positioned in the Congo, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Hydraulic Equal Tee

Dimensions of Hydraulic Equal Tee

Thread	CH	L1	L2	T	Pressure PN	Weight kg 100pcs	Series
Thread F1	mm	mm	mm	mm	bar
12×1,5	12	12	27	6	315	6,3	L
12×1,5	12	12	27	6	315	6,3	L
14×1,5	12	14	29	8	315	8,5	L
14×1,5	12	14	29	8	315	8,5	L
16×1,5	14	15	30	10	315	11,5	L
16×1,5	14	15	30	10	315	11,5	L
18×1,5	17	17	32	12	315	15,0	L
18×1,5	17	17	32	12	315	15,0	L
22×1,5	19	21	36	15	315	24,5	L
22×1,5	19	21	36	15	315	24,5	L
26×1,5	24	23,5	40	18	315	35,8	L
26×1,5	24	23,5	40	18	315	35,8	L
30×2	27	27,5	44	22	160	47,9	L
30×2	27	27,5	44	22	160	47,9	L
36×2	36	30,5	47	28	160	74,5	L
36×2	36	30,5	47	28	160	74,5	L
45×2	41	34,5	56	35	160	100,0	L
45×2	41	34,5	56	35	160	100,0	L
52×2	50	40	63	42	160	150,0	L
52×2	50	40	63	42	160	150,0	L
14×1,5	12	16	31	6	630	11,0	S
14×1,5	12	16	31	6	630	11,0	S
16×1,5	14	17	32	8	630	14,2	S
16×1,5	14	17	32	8	630	14,2	S
18×1,5	17	17,5	34	10	630	19,1	S
18×1,5	17	17,5	34	10	630	19,1	S
20×1,5	17	21,5	38	12	630	24,3	S
20×1,5	17	21,5	38	12	630	24,3	S
22×1,5	19	22	40	14	630	30,2	S
22×1,5	19	22	40	14	630	30,2	S
24×1,5	24	24,5	43	16	400	39,8	S
24×1,5	24	24,5	43	16	400	39,8	S
30×2	27	26,5	48	20	400	60,0	S
30×2	27	26,5	48	20	400	60,0	S
36×2	36	30	54	25	400	112,0	S
36×2	36	30	54	25	400	112,0	S
42×2	41	35,5	62	30	400	146,0	S
42×2	41	35,5	62	30	400	146,0	S
52×2	50	41	72	38	315	206,0	S
52×2	50	41	72	38	315	206,0	S

Hydraulic Equal Tee Assembled & Un Assembled Manufacturer in Lubumbashi, SS Hydraulic Equal Tee Exporter in Kinshasa, Hydraulic Reducing Tee Exporter in Mbuji-Mayi, DIN 2353 Hydraulic Tee Supplier in Kananga, Hydraulic Equal Tee Assembled & Un Assembled Exporter in Kisangani, Hydraulic Reducing Tee Supplier in Kisangani, Hydraulic Equal Tee Stockist in Lubumbashi, Congo

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Hydraulic Equal Tee in Kinshasa, Congo

You’ll find Hydraulic Equal Tee fittings widely used across various industries, including oil and gas, petrochemical, power generation, marine, and heavy machinery. They are perfect for hydraulic and pneumatic systems that demand precise fluid control and balanced flow distribution. These fittings guarantee safe and efficient operation in high-pressure environments like offshore platforms, industrial plants, and hydraulic equipment. Thanks to their sturdy construction, leak-proof design, and corrosion resistance, they are the go-to choice for modern hydraulic applications.

Hydraulic Equal Tee Uses

Hydraulic Equal Tee are widely used in hydraulic systems to split or disperse flow at a 90-degree angle. They are important in the oil and gas, fuel, automotive, and construction industries to guide flow between pipelines. These tees can effectively distribute or connect fluids, balancing pressure and flow in complex systems. Typical applications include hydraulic engines, energy generation, and water transfer systems, where they contribute to continuous operation, reduce system stress, and improve overall water consumption efficiency in high-pressure environments.
