Noah Tubefittings is a well-known manufacturer and supplier located in Kinshasa, Congo, specializing in top-notch **Inconel Hydraulic Fittings** that are built to perform exceptionally well in high-pressure and corrosive settings. These fittings are crafted to ensure secure, leak-proof connections in hydraulic systems that face extreme conditions. With a focus on precision technology and high-quality Inconel alloys, Noah Tubefittings guarantees that each fitting offers remarkable strength, durability, and resistance to oxidation and corrosion. Their Inconel Hydraulic Fittings are relied upon for their reliability, long lifespan, and consistent performance in tough industrial applications.
These fittings are primarily made up of nickel (up to 72%), chromium (14–17%), and iron (6–10%), along with trace amounts of molybdenum, niobium, and titanium. This unique blend gives them outstanding resistance to high-temperature oxidation, pitting, and stress corrosion cracking. They boast a tensile strength of around 965 MPa and a yield strength of about 550 MPa, ensuring excellent mechanical stability even under extreme thermal and pressure conditions.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | INCONEL 625, INCONEL 718, INCONEL 825, INCOLOY 800 |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | 6 MM TO 42 MM |
| CONNECTIONS | TUBE TO MALE THREAD , TUBE TO BUTT WELD , TUBE TO FEMALE THREAD , TUBE TO SOCKET WELD , TUBE TO TUBE , TUBE TO 24* CONE, TUBE TO JIC 37* , TUBE TO ADJUSTBALE STANDPIPE , TUBE TO SWIVEL END |
| WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO 24* CONE ,WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| Inconel | Element (% By Mass) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ni | Cr | Fe | Mo | Nb | Co | Mn | Cu | Al | Ti | Si | C | S | P | B | |
| 600 | 72.0 | 14.0–17.0 | 6.0–10.0 | 1.0 | 0.5 | 0.5 | 0.15 | 0.015 | |||||||
| 617 | 44.2–56.0 | 20.0–24.0 | 3.0 | 8.0–10.0 | 10.0–15.0 | 0.5 | 0.5 | 0.8–1.5 | 0.6 | 0.5 | 0.15 | 0.015 | 0.015 | 0.006 | |
| 625 | 58.0 | 20.0–23.0 | 5.0 | 8.0–10.0 | 3.15–4.15 | 1.0 | 0.5 | 0.4 | 0.4 | 0.5 | 0.1 | 0.015 | 0.015 | ||
| 690 | 59.5 | 30 | 9.2 | 0.35 | 0.01 | 0.02 | 0.35 | 0.019 | 0.003 | ||||||
| 718 | 50.0–55.0 | 17.0–21.0 | Balance | 2.8–3.3 | 4.75–5.5 | 1.0 | 0.35 | 0.2–0.8 | 0.65–1.15 | 0.3 | 0.35 | 0.08 | 0.015 | 0.015 | 0.006 |
| X-750 | 70.0 | 14.0–17.0 | 5.0–9.0 | 0.7–1.2 | 1.0 | 1.0 | 0.5 | 0.4–1.0 | 2.25–2.75 | 0.5 | 0.08 | 0.01 | |||
| Yield Strength 0.2% Proof (MPa) min | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Brinell (HB) max | Rockwell B (HR B) max | |||
| Psi – 75,000 , MPa – 517 | Psi – 1,35,000 , MPa -930 | 42.5 | – | – |
| Grade | UNS No | Old British | Euronorm | GOST | Japanese JIS | ||
| BS | En | No | AFNOR | ||||
| Inconel 600 Pipe | N06600 | NA 13 | NiCr15Fe | 2.4816 | NC15FE11M | МНЖМц 28-2,5-1,5 | NCF 600 |
| Inconel 625 | N06625 | NA 21 | NiCr22Mo9Nb | 2.4856 | NC22DNB4M | ХН75МБТЮ | NCF 625 |
| Inconel 601 | N06601 | NA 49 | NiCr23Fe | 2.4851 | NC23FeA | XH60BT | NCF 601 |
| Incoloy 825 | N08825 | NA 16 | NiCr21Mo | 2.4858 | NFE30C20DUM | ЭП703 | NCF 825 |
Contact us to get a quick quote for your requirement.
Inconel Hydraulic Fittings find their place in various industries, including oil and gas, chemical processing, aerospace, marine, and power generation. They are perfect for hydraulic and pneumatic systems that operate in harsh environments where corrosion resistance and mechanical integrity are vital. These fittings guarantee leak-free connections in high-pressure lines, offshore equipment, and refineries. Their remarkable durability and ability to endure extreme temperatures make them the go-to choice for applications that demand reliability, safety, and long-lasting performance.
Inconel Hydraulic Fittings are widely used in industries that require high performance under extreme conditions. In the oil and gas sector, they are essential for handling high-pressure and high-temperature fluids, ensuring reliable connections in offshore drilling and refining operations. In the aerospace industry, these fittings are used in hydraulic systems due to their ability to withstand extreme temperatures and corrosion. Additionally, they are employed in chemical processing plants, where resistance to acids and harsh chemicals is crucial. Their exceptional durability makes them ideal for nuclear power plants, marine applications, and other demanding environments.
Please feel free to contact us if you need any further information or for enquiry.
